Sisal Core

1.	Offered in both dry and pre-lubricated variety.
2.	Selection of Lubricants such as T55, Elaskon SKU, N65, N113 etc
3.	Available in 3 or 4 strands in Z or S twist as per requirement
4.	Can be packed in coils or Wooden Reels that can accommodate 200 to 500 Kgs of cores in longer lengths

Sisal Yarn

Availability	Available in Left or Right Twist
Selection	Clipped or Un-Clipped
Weight	Offered in 1250 m/kg to 200m/kg
Packing	Packages in Cheese Spools of dimensions and weight as required by the customer

Polypropylene Battle Rope/Gym Rope

Size	Features	Advantages
As per your requirement	High perforfance Polypropylene Yarns	Great for cross training. Improving one’s overall fitness level. Great for strength, power and cardiovascular endurance.
As per your requirement	Colour as per your requirement	Extra Durable

cargo nets

High Lights:

– Available in sizes as per requirement
– Polypropylene Nets can be in any colour as per requirement
– Long Lasting
– Strong

16 Strand Braided Ropes

Nylon (Polyamide) /Polyester/Polypropylene braids offer high strength, reliability and flexibility. These can be made with Hollow/Solid core and in any colour as may be required with or without UV treatment. Currently available in 3-12mm diameter.

PP Twines

Our Fishing Twines are made with superior-quality yarns for great performance and life in the most demanding marine conditions.

PP Fishing Ropes

Our fishing ropes offer abrasion resistance and can be made to individual colour requirements in three and four strands.

PP Fencing Rope

Size	Twist	Features	Advantages
As Per Requirement	LH/RH	High Grade Stainless Steel Wires, Enhanced Polyprylene Yarns	Extra Durable

Jute Baler Twine

Size (mm)	Features	Break Strength
2	Prime quality Jute Yarns	50

Polypropylene Baler Twine

Denier	Twist	Features	Break Strength
14400	LH/RH	Split Film Polypropylene Yarns	50
18000	LH/RH		72
20000	LH/RH		80
24000	LH/RH		96

Transmission Line Ropes

Our PP ropes designed for cable pulling and tower erection are known for their strength, durability and abrasion resistance.

Submersible Ropes

Our PP ropes specifically designed for installation of submersible pumps provide the highest safety due to their strength, durability and endurance.

Jute Rope

Manila and Sisal Ropes

Technical Data

“Dia (mm)”	Manila Rope		Sisal Rope		Manila Rope		Sisal Rope
	Linear Densiy (g/m)		Linear Densiy (g/m)		Breaking Strength (min.) kN (kgf)		Breaking Strength (min.) kN (kgf)
	3 Strands	4 Strands	3 Strands	4 Strands	3 Strands	4 Strands	3 Strands	4 Strands
6	32	N/A	29	N/A	2.94 (303)		2.550 (260)	N/A
8	54	54	54	N/A	5.45 (556)	4.81 (490)	4.735 (483)	N/A
10	68	68	68	N/A	7.04 (718)	6.27 (639)	6.226 (635)	N/A
12	105	105	105	105	10.64 (1 085)	9.41 (960)	9.363 (955)	8.431 (860)
14	140	140	140	140	14.50 (1 479)	12.80 (1 305)	12.698 (1 285)	11.324 (1 155)
16	190	190	190	190	20.30 (2 070)	17.90 (1 825)	17.696 (1 804)	15.931 (1 624)
18	220	220	220	220	24.40 (2 488)	21.53 (2 195)	20.932 (2 134)	18.824 (1 919)
20	275	275	275	275	32.40 (3 304)	28.68 (2 924)	27.981 (2 853)	25.098 (2 559)
22	330	330	330	330	38.59 (3 935)	34.08 (3 067)	33.383 (3 404)	30.049 (3 064)
24	400	400	400	400	45.70 (4 660)	40.36 (4 116)	39.853 (4 064)	35.883 (3 659)
26	470	470	470	470	53.35 (5 440)	47.07 (4 800)	46.324 (4 724)	41 .667 (4 249)
28	532	532	532	532	60.94 (6 214)	53.79 (5 485)	52.206 (5 323)	46.961 (4 789)
30	625	625	625	625	68.59 (6 994)	60.56 (6 175)	59.755 (6 093)	53.775 (5 483)
32	740	700	700	700	78.75 (8 030)	69.53 (7 090)	67.255 (6 858)	60.540 (6 173)
36	890	890	890	890	96.50 (9 840)	85.17 (8 685)	84.637 (8 630)	85.981 (8 767)
40	1 100	1 100	1100	1100

Manila Rope		Sisal Rope
Linear Densiy (g/m)		Linear Densiy (g/m)		Breaking Strength (min.) kN (kgf)		Breaking Strength (min.) kN (kgf)
3 Strands	4 Strands	3 Strands	4 Strands	3 Strands	4 Strands	3 Strands	4 Strands
6	32	N/A	29	N/A	2.94 (303)		2.550 (260)	N/A
8	54	54	54	N/A	5.45 (556)	4.81 (490)	4.735 (483)	N/A
10	68	68	68	N/A	7.04 (718)	6.27 (639)	6.226 (635)	N/A
12	105	105	105	105	10.64 (1 085)	9.41 (960)	9.363 (955)	8.431 (860)
14	140	140	140	140	14.50 (1 479)	12.80 (1 305)	12.698 (1 285)	11.324 (1 155)
16	190	190	190	190	20.30 (2 070)	17.90 (1 825)	17.696 (1 804)	15.931 (1 624)
18	220	220	220	220	24.40 (2 488)	21.53 (2 195)	20.932 (2 134)	18.824 (1 919)
20	275	275	275	275	32.40 (3 304)	28.68 (2 924)	27.981 (2 853)	25.098 (2 559)
22	330	330	330	330	38.59 (3 935)	34.08 (3 067)	33.383 (3 404)	30.049 (3 064)
24	400	400	400	400	45.70 (4 660)	40.36 (4 116)	39.853 (4 064)	35.883 (3 659)
26	470	470	470	470	53.35 (5 440)	47.07 (4 800)	46.324 (4 724)	41 .667 (4 249)
28	532	532	532	532	60.94 (6 214)	53.79 (5 485)	52.206 (5 323)	46.961 (4 789)
30	625	625	625	625	68.59 (6 994)	60.56 (6 175)	59.755 (6 093)	53.775 (5 483)
32	740	700	700	700	78.75 (8 030)	69.53 (7 090)	67.255 (6 858)	60.540 (6 173)
36	890	890	890	890	96.50 (9 840)	85.17 (8 685)	84.637 (8 630)	85.981 (8 767)
40	1 100	1 100	1100	1100	119.60 (12 196)	105.37 (10 745)	102.109(10412)	91.912 (9372)

Polypropylene Rope

Material	UV Stabilized Fibrillated – danline Polypropylene Split Film
Construction	3-Strand
Specific Gravity	0.92
Melting Point	165°C
Dry & Wet Conditions	Identical dry & wet strengths
U.V. Resistance	Good
Chemical Resistance	Very Good

Technical Data

Dia in MM (3 Strand)	Wt./coli of 220 MTR	Break Strength (Kgf)
4.0	1.8	286
6.0	4.1	612
8.0	7.3	1120
10.0	11.4	1530
12.0	16.5	2162
14.0	22.4	2856
16.0	29.3	3825
18.0	37.1	4590
20.0	45.8	5712
22.0	55.4	6834
24.0	65.9	8160
26.0	77.3	9180
28.0	89.7	10812
30.0	103.0	12036
32.0	117.1	13464
36.0	148.3	17340
40.0	183.0	20400

Polyester Rope

Material	UV Stabilized Polyester Yarns
Construction	3/4 Strand
Specific Gravity	1.38
Melting Point	250°C
Chemical Resistance	Excellent
U.V. Resistance	Very Good
Abrasion Resistance	Very Good

Technical Data

Dia in MM (3 Strand)	Wt./coli of 220 MTR	Break Strength (Kgf)
4.0	2.6	290
6.0	5.9	554
8.0	10.6	1000
10.0	16.5	1560
12.0	23.8	2230
14.0	32.3	3120
16.0	42.2	3980
18.0	53.5	4980
20.0	66.0	6230
22.0	79.9	7470
24.0	95.0	8960
26.0	111.5	10500
28.0	129.4	12000
30.0	148.5	13400
32.0	169.0	15400
36.0	213.8	19000
40.0	264.0	23500

Nylon/Polyamide Rope

Material	Multiﬁlament Yarns
Construction	3/4 Strand
Specific Gravity	1.14
U.V. Resistance	Very Good
Abrasion Resistance	Excellent
Chemical Resistance	Excellent
Melting Point	215°C
Dry & Wet Conditions	Strength decreases 15% when wet

Technical Data

Dia in MM (3 Strand)	Wt / coil of 220 MTR	Kgf
4.0	2.3	320
6.0	5.1	750
8.0	9.2	1345
10.0	14.3	2088
12.0	20.6	2995
14.0	28.0	4095
16.0	36.6	5300
18.0	46.3	6695
20.0	57.2	8300
22.0	69.2	10000
24.0	82.4	12000
26.0	96.7	13950
28.0	112.1	15800
30.0	128.7	17755
32.0	146.4	20000
36.0	185.3	24500
40.0	228.8	30000

Jute Core

Material	High precision Jute Yarns
Construction	3-Strand, 4 Strand (as per your specifications)
Size	As per your specifications

Polypropelene Core

Material	Special Precision Polypropylene Yarns
Construction	3-Strand, 4 Strand (as per your specifications)
Size	As per your specifications
Colour	As per your requirement
Melting Point	165°C
Dry & Wet Conditions	Identical dry & wet strengths
U.V. Resistance	Good (if asked for)
Packaging	Coils/Reels as per your specifications
